Sep. 8, 2021 Research Highlight Biology

Experimentally reconstructing the reorganization of chromosomal DNA during mitosis

An assay that replicates early mitosis reveals how one enzyme first untangles and then winds up chromosomal DNA into compactly organized structures

image of mitotic chromatids Figure 1: A cluster of mitotic chromatids made by combining chromosomal DNA with six purified proteins. The chromatids are bound with many topoisomerase IIα molecules (labeled green in both images); DNA is labeled blue (left) and magenta (right); a chromatid-binding protein complex called condensin is labeled red (left). © 2021 RIKEN Chromosome Dynamics Laboratory

Two RIKEN researchers have discovered how, during cell division, one enzyme helps facilitate the tightly coordinated reorganization of chromosomal DNA into compact structures that can be evenly divided amongst the two resulting daughter cells1.

Ever since the dynamics of chromosomes undergoing mitosis—the process by which a cell splits into two identical daughter cells—were first described about 140 years ago, scientists have been trying to better understand the intricacies of this process.

In the run-up to mitosis, each chromosome undergoes replication to form a pair of identical chromatids, with one chromatid slated for each daughter cell. By the time division begins, these two long chains of DNA have assembled into a pair of distinct, highly condensed structures, which are temporarily tethered to each other at their centers.

In 2015, Keishi Shintomi and Tatsuya Hirano, both of the RIKEN Chromosome Dynamics Laboratory, developed an assay that allowed them to induce chromatid assembly by combining isolated sperm nuclei with a mixture of six proteins. “Reconstituting a cellular process in a test tube using purified components is one of the most powerful approaches for dissecting and comprehending that process,” explains Hirano.

While this technique has given valuable insights into the early stages of mitosis, critical elements of the chromatid assembly process remained poorly understood. In particular, Shintomi and Hirano sought to discover the role of topoisomerase IIα—one of the six proteins required for this assay—and set about optimizing their method in order to better characterize the function of this enzyme.

Picture of Keishi Shintomi Keishi Shintomi (shown) and RIKEN colleague Tatsuya Hirano have developed an assay that recapitulates early mitosis and have used it to show how one enzyme first untangles and then winds up chromosomal DNA into compactly organized structures. © 2021 RIKEN

Their experiments revealed that topoisomerase IIα plays two roles in chromatid assembly. “The first is to dissolve entanglements between chromatids,” says Shintomi. “While the second is to generate intra-chromatid entanglements that support condensation.”

The disentangling function of topoisomerase IIα has been reported before, but the latter activity was unexpected. It appears to occur only when the enzyme is in a highly crowded environment with closely packed DNA strands. The two researchers were also able to identify a critical domain in topoisomerase IIα that directly coordinates the ‘knotting up’ of DNA during the chromatid condensation process.

Shintomi and Hirano are now keen to characterize other molecules that interact with topoisomerase IIα as part of the condensation process, including a class of DNA-binding proteins called linker histones. These proteins were absent in the researchers’ original chromatid assembly assay, but the present study indicates that they interact with the same chromosomal regions that ultimately get targeted for proper actions of topoisomerase IIα.

“Such efforts will shed new light on the previously unrecognized action of linker histones and fierce competition among chromosomal proteins in the crowded environments of mitotic chromosome assembly,” says Hirano.

Related contents


  • 1. Shintomi, K. & Hirano, T. Guiding functions of the C-terminal domain of topoisomerase IIα advance mitotic chromosome assembly. Nature Communications 12 2917 (2021). doi: 10.1038/s41467-021-23205-w
